The electrical system of the stage hoist motor is the core that ensures the hoist operates "without jamming or sudden speed changes". Through precise control of the motor, it meets the strict requirements for "smooth movement" in stage performances:
Stepless Speed Regulation and Soft Start-Stop Technology Unlike the "fixed gear speed regulation" of ordinary hoists, the control system of the stage hoist motor can achieve "stepless speed regulation" through a Variable Frequency Drive (VFD). The motor speed can smoothly increase from 0 to the rated speed and slowly decelerate when descending, avoiding load shaking caused by "sudden acceleration/deceleration" (for example, sudden speed changes of a lighting frame may cause deviations in the projection position of the lights). At the same time, the soft start-stop function can control the starting current within 1.2 times the rated current (the starting current of ordinary hoists often reaches 3-5 times), which not only protects the motor but also avoids "electrical impact vibration" caused by sudden current changes.
Bidirectional Precise Positioning and Self-locking The control system is equipped with a high-precision encoder (such as a photoelectric encoder) that can real-time feedback the operating position of the stage hoist motor (with an accuracy of ±1mm). Cooperating with a PLC (Programmable Logic Controller), it realizes "fixed-point start-stop". For example, when a scenery needs to be accurately stopped at a height of 3.5 meters on the stage, the system can automatically cut off the power and achieve "instant self-locking" through an electromagnetic brake, eliminating "slipping" or "position drift" and ensuring stable equipment status during performances.
Anti-interference Electrical Design There are a large number of strong electromagnetic equipment such as lighting and audio in the stage environment. The electrical system of the stage hoist motor adopts a "shielded cable + filtering module" design, which can resist external electromagnetic interference, avoid "misoperation" caused by signal disorder (such as sudden stops or direction confusion), and ensure that the operating logic is completely consistent with the control instructions.
